3-7
Cisco 3600 Series Routers Hardware Installation Guide
OL-2056-05
Chapter 3 Installing the Router
Installing the Chassis
Figure 3-8 Cisco 3620 or Cisco 3640 Bracket Attachment—Front Panel Forward
(23- or 24-Inch Rack)
Figure 3-9 Cisco 3631 Bracket Attachment—Front Panel Forward (19- and 23-Inch Racks)
H6252
0
ACTIVE
READ
Y
123
P
C
M
C
IA
1
0
Note: The second bracket attaches to the other side of the chassis.
82535
LEFT
Left (narrow) bracket
for 19-inch rack
Right (wide) bracket
for 19-inch rack
Left bracket
for 23-inch rack
RIGHT
S
E
R
IE
S
23" ETSI, NEBS
RIGHT
Right bracket
for 23-inch rack
23" ETSI, NEBS
LEFT
Use two screws on each side.
