3-12
Cisco 3700 Series Routers Hardware Installation Guide
OL-2180-08
Chapter 3 Installing the Router
Power Connections
Connecting Routers to AC Power
If your router uses AC power, connect it to a 15 A, 120 VAC (10 A, 240 VAC) circuit with overcurrent
protection.
Note The input voltage tolerance limits for AC power are 85 and 264 VAC.
Warning AC connected units must have a permanent ground connection in addition to the power cable ground
wire. NEBS-compliant grounding satisfies this requirement. Statement 284
Warning This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that
the protective device is rated not greater than:
15A, 120VAC (10A, 240VAC). Statement 1005
Caution To comply with Telcordia NEBS GR-1089-Core and EN 300386 requirements, you must use foil
twisted-pair cable that is properly grounded at both ends.
Connecting Routers to a DC-Input Power Supply
Warning Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Statement 1003
Warning Use copper conductors only. Statement 1025
Note The installation must comply with the 1996 National Electric Code (NEC) and other applicable codes.
If your router has a DC-input power supply, follow the directions in this section for proper wiring.
A router with a DC-input power supply has a terminal block for the DC power connections.
Depending on the type of router you are installing, see one of the following procedures:
• Wiring the DC-Input Power Supply in Cisco 3725 Routers, page 3-12
• Wiring the DC-Input Power Supply in Cisco 3745 Routers, page 3-17
Wiring the DC-Input Power Supply in Cisco 3725 Routers
If your Cisco 3725 router has a DC-input power supply, follow the directions in this section for proper
wiring.

Cisco 3700 series Specifications

General

Connectivity Technology	Wired
Operating System	Cisco IOS
Operating Temperature	32 to 104°F (0 to 40°C)
Storage Temperature	-4 to 149°F (-20 to 65°C)
Routing Protocols	BGP, OSPF, EIGRP, RIP, IS-IS
Network Management	SNMP, CiscoWorks
Security Features	ACLs, VPN, Firewall, RADIUS, TACACS+
Product Type	Network Router
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet, Serial, Frame Relay, ATM
Network/Transport Protocol	TCP/IP, UDP
Remote Management Protocol	SNMP, Telnet, SSH
Features	Quality of Service (QoS)
WAN Interfaces	Serial, ISDN, Frame Relay, ATM
LAN Interfaces	Ethernet, Fast Ethernet, Gigabit Ethernet
Processor	Motorola PowerPC
Interfaces	Variety of modular interface cards including Ethernet, Fast Ethernet, Gigabit Ethernet, Serial, ISDN, ATM, and Voice/WAN Interface Cards (VICs/VWICs)
