Cisco 3700 Series Routers Hardware Installation Guide
OL-2180-08
Appendix C Configuration Register
Enabling Booting from CompactFlash Memory
Enabling Booting from CompactFlash Memory
To enable booting from CompactFlash memory, set bits 3, 2, 1, and 0 to a value between 2 to 15. To
specify a filename to boot, enter the system software configuration command boot system flash
[device:] [partition:] [filename] in the configuration file.
By specifying the device and partition in the command, you can configure the router to boot from an
external CompactFlash card. If you specify only the filename, the router is configured to boot from
internal CompactFlash memory.
To enter global configuration mode while in the system software image, enter the configure command
at the enable prompt, as in the following example:
Router# configure
Configuring from terminal, memory, or network [terminal]? terminal
Enter configuration commands, one per line.
Edit with DELETE, CTRL/W, and CTRL/U; end with CTRL/Z
boot system flash filename
To disable Break and enable the boot system flash command, enter the config-register command with
a value, as follows:
Router(config)# config-reg 0x102
Router(config)# Ctrl-z
If you set the configuration register value to 0x102, as in this example, you need not enter the
boot system flash command unless more than one image is in CompactFlash memory.
Table C-4 System Console Terminal Data Rate Settings
Data Rate Bit 5 Bit 12 Bit 11
115200 1 1 1
57600 1 1 0
38400 1 0 1
19200 1 0 0
9600 0 0 0
4800 0 0 1
2400 0 1 1
1200 0 1 0

Cisco 3700 series Specifications

General

Connectivity Technology	Wired
Operating System	Cisco IOS
Operating Temperature	32 to 104°F (0 to 40°C)
Storage Temperature	-4 to 149°F (-20 to 65°C)
Routing Protocols	BGP, OSPF, EIGRP, RIP, IS-IS
Network Management	SNMP, CiscoWorks
Security Features	ACLs, VPN, Firewall, RADIUS, TACACS+
Product Type	Network Router
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet, Serial, Frame Relay, ATM
Network/Transport Protocol	TCP/IP, UDP
Remote Management Protocol	SNMP, Telnet, SSH
Features	Quality of Service (QoS)
WAN Interfaces	Serial, ISDN, Frame Relay, ATM
LAN Interfaces	Ethernet, Fast Ethernet, Gigabit Ethernet
Processor	Motorola PowerPC
Interfaces	Variety of modular interface cards including Ethernet, Fast Ethernet, Gigabit Ethernet, Serial, ISDN, ATM, and Voice/WAN Interface Cards (VICs/VWICs)
