Cisco 5510 - ASA SSL / IPsec VPN Edition Hardware Installation Guide

C-2
Cisco ASA 5500 Series Hardware Installation Guide
OL-10089-01
Appendix C Cable Pinouts
Console Port (RJ-45)
Figure C-2 10/100/1000 Port Pinouts
Console Port (RJ-45)
Cisco products use the following three types of RJ-45 cables:
• Straight-through
• Crossover
Note Cisco does not provide these cables; they are widely available from other sources.
Figure C-3 shows the RJ 45 cable.
Figure C-3 RJ-45 Cable
To identify the RJ-45 cable type, hold the two ends of the cable next to each other so that you can see
the colored wires inside the ends, as shown in Figure C-4.
Figure C-4 RJ-45 Cable Identification
60915
231 45678Pin Label
1
2
3
4
5
6
7
8
TP0+
TP0-
TP1+
TP2+
TP2-
TP1-
TP3+
TP3-
H2936
8 7 6 5 4 3 2 1
RJ-45 connector
H5663
