Cisco 6821 Administration Guide

Wi-Fi Settings
DescriptionParameter
Allows you to turn on or off the Wi-Fi on your phone.
Select Yes if you want to turn on the Wi-Fi and No
if you want to turn it off.
Default: Yes
Phone-wifi-on
Allows you to select a way to connect the phone to a
wireless network. The options are:
• WLAN: This option requires the user to enter
the credentials on the phone to connect to a
protected wireless network.
• WPS: The user can connect the phone to a
wireless network using either the WPS button
on the access point or the PIN code.
Phone-wifi-type
Wi-Fi Profile (n)
DescriptionParameter
Allows you to enter a name for the SSID. This name
displays on the phone. Multiple profiles can have the
same network name with different security mode.
Network Name
Allows you to select the authentication method that
is used to secure access to the Wi-Fi network.
Depending on the method you choose, a password,
passphrase, or key field appears so that you can
provide the credentials that are required to join this
Wi-Fi network. Options are:
• Auto
• EAP-FAST
• PEAP-GTC
• PEAP-MSCHAPV2
• PSK
• WEP
• None
Default: None
Security Mode
Cisco IP Phone 6800 Series Multiplatform Phones Administration Guide
229
Phone Troubleshooting
Wi-Fi Settings

Cisco 6821 Specifications

General

Resolution	320 x 240 pixels
Speakerphone	Yes
Headset Port	Yes
Protocols	SIP
USB Port	No
Wireless	No
Bluetooth	No
Video Support	No
Conference Capabilities	Yes
Wall Mountable	Yes
Display	3.5-inch grayscale
Ethernet	10/100 Ethernet
Line Keys	2
PoE	IEEE 802.3af Power over Ethernet (PoE)
Codecs	G.711, G.722, G.729, iLBC
Weight	2.0 lb (0.91 kg)
