DescriptionParameter
The parameter by which the user agent will identify
itself for this line. If this field is blank, the actual URI
used in the SIP signaling should be automatically
formed as:
sip:UserName@Domain
where UserName is the username given for this line
in the User ID, and Domain is the domain given for
this profile in the User Agent Domain. If the User
Agent Domain is an empty string, then the IP address
of the phone should be used for the domain.
If the URI field is not empty, but if a SIP or SIPS URI
contains no @ character, the actual URI used in the
SIP signaling should be automatically formed by
appending this parameter with an @ character
followed by the IP address of the device.
SIP URI
XSI Line Service
DescriptionParameter
Enter the name of the server; for example, .
xsi.iop1.broadworks.net
XSI Host Server uses http protocol by
default. To enable XSI over HTTPS, you
can specify https:// in the server.
Note
For example:
https://xsi.iop1.broadworks.net
You can also specify a port for the server.
For example:
https://xsi.iop1.broadworks.net:5061
If you don't specify a port. The default port for the
specified protocol is used.
Default: Blank
XSI Host Server
Determines the XSI authentication type. Select Login
Credentials to authenticate access with Login User
ID and Login Password. Select SIP Credentials to
authenticate access with the register Auth ID and
Password of the SIP account registered on the phone.
Default: Login Credentials
XSI Authentication Type
Cisco IP Phone 6800 Series Multiplatform Phones Administration Guide
287
Phone Troubleshooting
XSI Line Service
