Cisco 7600 Series Module Guide

Contents
v
Cisco 7600 Series Router Module Guide
OL-9392-05
1-Port OC-12 ATM Module (WS-X6101-OC12-SMF) 3-2
ATM Module LEDs 3-3
CHAPTER 4 FlexWAN Module and Enhanced FlexWAN Modules 4-1
CHAPTER 5 Multilayer Switch Module 5-1
CHAPTER 6 Network Analysis Modules 6-1
Network Analysis Module (WS-SVC-NAM-1) 6-1
Network Analysis Module (WS-SVC-NAM-2) 6-2
CHAPTER 7 Firewall Services Module 7-1
CHAPTER 8 IPSec VPN Acceleration Services Module 8-1
CHAPTER 9 Intrusion Detection System Module 9-1
CHAPTER 10 Content Switching Module 10-1
CHAPTER 11 Switch Fabric Modules 11-1
Switch Fabric Module (WS-C6500-SFM) 11-1
Switch Fabric Module 2 (WS-X6500-SFM2) 11-2
CHAPTER 12 Voice-Related Modules 12-1
Communications Media Module (WS-SVC-CMM) 12-1
8-Port T1/E1 PSTN Interface Module (WS-X6608-T1/E1) 12-4
24-Port FXS Analog Interface Module (WS-X6624-FXS) 12-6
CHAPTER 13 Cisco 7600 Series Ethernet Services 20G Line Cards 13-1
Cisco 7600 Series Ethernet Services 20G Line Cards 13-1
Cisco 7600-ES20-10G Line Card LEDs 13-1
Cisco 7600-ES20-GE Line Card LEDs 13-2
CHAPTER 14 Cisco Application Control Engine Module 14-1
CHAPTER 15 Cisco 7600 Ethernet Services Plus Line Cards 15-1
Cisco 7600 Ethernet Services Plus Line Cards 15-1

Cisco 7600 Series Specifications

General

Category	Network Router
Port Density	Varies by module
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet
Redundancy	Power supplies
Power Supply	AC or DC, Redundant options available
Operating System	Cisco IOS XR
Management	CLI, SNMP
Form Factor	Modular
Dimensions	Varies by chassis model
Weight	Varies by chassis model and configuration
Chassis Slots	6, 9, or 13
