9-2
Cisco 7600 Series Router Module Guide
OL-9392-05
Chapter 9 Intrusion Detection System Module
Table 9-1 describes the Intrusion Detection System Module states as indicated by the STATUS LED.
The SHUTDOWN button manually shuts down the Intrusion Detection System Module. To prevent
corruption of the module, it is critical that you shut down the module properly. To properly shut down
the switching module, session into the Intrusion Detection System Module from the Cisco 7600 series
router console and enter the shutdown command. If the Intrusion Detection System Module fails to
respond to the shutdown command, press the SHUTDOWN button to manually shut down the Intrusion
Detection System Module.
Caution Do not remove the Intrusion Detection System Module from the switch until after the module shuts down
completely. Removing the module without going through a shutdown procedure can damage the module.
Use a small pointed object, such as a paper clip, to access the SHUTDOWN button and turn off the
Intrusion Detection System Module. The shutdown procedure may take several minutes.
The HD (hard drive) activity LED indicates when the hard drive is in use.
The PCMCIA slot provides access for up to two standard PCMCIA cards and is reserved for future use.
Ta b l e 9-1 Intrusion Detection System Module STATUS LED Description
Color/State Description
Green All diagnostics test pass. The module is operational.
Red A diagnostic other than an individual port test failed.
Amber The module is running through its boot and self-test
diagnostics sequence.
The IDSM is disabled.
Off The IDSM power is off.
