Cisco 7600 Series Module Guide

12-7
Cisco 7600 Series Router Module Guide
OL-9392-05
Chapter 12 Voice-Related Modules
24-Port FXS Analog Interface Module (WS-X6624-FXS)
Ta b l e 12-5 24-Port FXS Analog Interface Module LEDs
LED Color/State Description
STATUS Green The module is online and operational.
Orange The module is booting or running diagnostics.
The supervisor engine has disabled the module.
The supervisor engine has sent an “SCP_SET_DIAG_FEATURES”
message indicating that the diagnostics have failed.
An overtemperature condition has occurred. (A minor temperature
threshold has been exceeded during environmental monitoring.)
Red The module processor powered up but is not running.
The module processor detected a fatal error during its diagnostics.
An overtemperature condition has occurred. (A major temperature
threshold has been exceeded during environmental monitoring.)
Off The module is not receiving power. The module was powered down
due to insufficient power. (The module is listed as power-deny in the
show module status field.)
Port number Green The telephone or fax machine is off-hook.
Yellow The module or port is disabled through the CLI
1
.
1. CLI = command-line interface
Off The port is not active (connected device is on-hook) or the link is
not connected.

Cisco 7600 Series Specifications

General

Category	Network Router
Port Density	Varies by module
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet
Redundancy	Power supplies
Power Supply	AC or DC, Redundant options available
Operating System	Cisco IOS XR
Management	CLI, SNMP
Form Factor	Modular
Dimensions	Varies by chassis model
Weight	Varies by chassis model and configuration
Chassis Slots	6, 9, or 13
