Cisco 7600 Series Module Guide

14-2
Cisco 7600 Series Router Module Guide
OL-9392-05
Chapter 14 Cisco Application Control Engine Module
Ta b l e 14-1 Content Switching Module STATUS LED
Color/State Description
Green • The module is operational; the supervisor engine has
provided module online status.
Orange • The module is initializing hardware or communicating
with the supervisor engine.
• A fault occurred during the initialization sequence.
• The module failed to download its Field Programmable
Gate Arrays (FPGAs) at startup. The module continues
with the remainder of the initialization sequence and
provides the module online status from the supervisor
engine.
• The module has not received module online status from
the supervisor engine. This problem may be caused by the
supervisor engine detecting a failure in an external
loopback test that it issued to the module.
Green to
Orange
• The module is disabled through the supervisor engine
command line interface (CLI) using the no power enable
module command.
Red • The module is released from reset by the supervisor
engine and is booting.
• The boot code failed to run.
Off The module is waiting for the supervisor engine to provide
power.
• The module is offline.
• The module is not receiving power, which may be caused
by one of the following:
– Power is not available to the module.
– Module temperature is over the limit1 .

Cisco 7600 Series Specifications

General

Category	Network Router
Port Density	Varies by module
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet
Redundancy	Power supplies
Power Supply	AC or DC, Redundant options available
Operating System	Cisco IOS XR
Management	CLI, SNMP
Form Factor	Modular
Dimensions	Varies by chassis model
Weight	Varies by chassis model and configuration
Chassis Slots	6, 9, or 13
