Chapter 6 Customizing the Cisco Unified IP Phone
Creating Custom Background Images
Tip Many graphics programs provide a feature that will resize a graphic. An easy way to create a thumbnail
image is to first create and save the full size image, then use the sizing feature in the graphics program
to create a version of that image that is 25% of the original size. Save the thumbnail version by using a
different name.
The PNG files for background images must meet the following requirements for proper display on the
Cisco Unified IP Phone:
• Full size image—320 pixels (width) X 212 pixels (height).
• Thumbnail image—80 pixels (width) X 53 pixels (height).
• Color palette—Includes up to 16-bit color (65535 colors). You can use more than 16-bit color, but
the phone will reduce the color palette to 16-bit before displaying the image. For best results, reduce
the color palette of an image to 16-bit when you create a PNG file.
Tip If you are using a graphics program that supports a posterize feature for specifying the number
of tonal levels per color channel, set the number of tonal levels per channel to 40 (40 red X 40
green X 40 blue = 64000 colors). This is as close as you can posterize to 65535 colors without
exceeding the maximum.
Configuring a Custom Background Image
To create custom background images for the Cisco Unified IP Phone, follow these steps:
Procedure
Step 1 Create two PNG files for each image (a full size version and a thumbnail version). Ensure the PNG files
comply with the format guidelines that are listed in the “PNG File Requirements for Custom Background
Images” section on page 6-4.
Step 2 Upload the new PNG files that you created to the following subdirectory in the TFTP server for the Cisco
Unified Communications Manager:
/Desktops/320x216x16
Note The file name and subdirectory parameters are case sensitive. Be sure to use the forward slash
“/” when you specify the subdirectory path.
To upload the files, choose Software Upgrades > Upload TFTP Server File in Cisco Unified
Communications Operating System Administration. For more information, see the “Software Upgrades”
chapter in Cisco Unified Communications Operating System Administration Guide.
Note If the folder does not exist, the folder gets created and the files get uploaded to the folder.
Step 3 You must also copy the customized images and files to the other TFTP servers that the phone may contact
to obtain these files.

Cisco 7975G Specifications

General

Handset type	Wired handset
Product type	IP Phone
Product color	Grey, Silver
Speakerphone	Yes
Voice codecs	G.711Mu, G.711a, G.722, G.729A, iLBC
Number of melodies	24
Aspect ratio	4:3
Display diagonal	5.6 \
Display resolution	320 x 240 pixels
Lines quantity	8 lines
Phonebook capacity	- entries
Number of VoIP accounts	-
Front camera	No
Security algorithms	128-bit AES
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	DHCP, TFTP
Volume control	Digital
Headphone outputs	1
Ethernet LAN (RJ-45) ports	2
Number of handles included	1 pc(s)
AC adapter output voltage	48 V
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Certification	FCC

Weight and Dimensions

Depth	152.4 mm
Width	266.7 mm
Height	203.2 mm
Weight	1600 g
