A-6
Cisco Integrated Services Router Hardware Installation Guide
Appendix A Technical Specifications
Cisco 810 Series
Standard Safety
Certifications
UL 60950-1, 2nd edition; CAN/CSA C22.2 No. 60950-1,
2nd edition, EN 60950-1, 2nd edition; CB to IEC
60950-1, 2nd edition with all group differences and
national deviations
UL 60950-1, 2nd edition;
CAN/CSA C22.2 No. 60950-1, 2nd
edition, EN 60950-1, 2nd edition;
CB to IEC 60950-1, 2nd edition
with all group differences and
national deviations; S/NZS
60950-1, first edition
(Australia/New Zealand)
EMC Emissions EN55022/CISPR22, CFR 47 Part 15, ICES003, VCCI-V-3, AS/NZS CISPR22, CNS13438,
CISPR22, CNS13438, EN300-386, EN61000-3-2, EN61000-3-3, and EN61000-6-1
EMC Immunity EN55024/CISPR24, (EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5,
EN61000-4-6, EN61000-4-11), and EN300-386
Radio Immunity EN301 489-1, EN 301 489-7, and EN301 489-24
Transportation/Storage Conditions
Temperature –40 to158°F (–40 to 70°C) –40 to185°F
(–40 to 85°C)
Humidity 5–95%
Altitude 4570 m (15,000 ft)
Router AC Power Adapter
1
Input Voltage 85–264 VAC
100–240 VAC nominal
Maximum Power
Consumption
25 W
Maximum Output Power
Rating
20 W
(5 VDC, 4 Amps)
Router DC Power Adapter
Input Voltage 12 VDC nominal
PWRx-20W-12VDC (10 VDC to 36 VDC operating range)
24 VDC nominal
PWRx-20W-24VDC (18 VDC to 75 VDC operating range)
Maximum Power
Consumption
25 W
Maximum Output Power
Rating
20 W
(5 VDC, 4 Amps)
Table A-3 Cisco 819 ISR Specifications (continued)
Description
Hardened Design
Specification
(Cisco 819HG and Cisco
819HG-4G ISRs)
Non-Hardened Design
Specifications
(Cisco 819G and Cisco
819G-4G ISRs)
Hardened Design Specifications
(C819HGW and C819HWD ISRs)
