Cisco 800 Series Hardware Installation Guide

A-27
Cisco Integrated Services Router Hardware Installation Guide
Appendix A Technical Specifications
Cisco 860, 880, 890 Series
Voice ISDN BRI Interface Pin Numbers and Functions
Table A-27 lists the interface pin numbers and functions for the voice ISDN BRI port.
SFP Port Connector Pinouts
Table A-28 lists the pinouts for the SFP port.
7Unused
8Unused
Table A-26 Data BRI Port Pinouts (continued)
Pin Function
Table A-27 Interface Pin Numbers and Functions
ISDN BRI NT/TE Card NT Interface
1
1. Use a straight-through cable for NT interfaces.
TE Interface
2
2. Use a crossover cable for TE interfaces.
Pin 3/T+ Pin 3/R+ Pin 3/T+
Pin 4/R+ Pin 4/T+ Pin 4/R+
Pin 5/R- Pin 5/T- Pin 5/R-
Pin 6/T- Pin 6/R- Pin 6/T-
Table A-28 SFP Port Pinouts
Pin Function
1 TX Ground
2TX Fault
3TX disable
4 Module definition 2
5 Module definition 1
6 Module definition 0
7 Rate Select
8 Loss of signal
9 Receiver ground
10 Receiver ground
11 Receiver ground
12 Inverted received data out
13 Received data out
14 Receiver ground
15 Receiver power

Cisco 800 Series Specifications

General

Model	Cisco 800 Series
Category	Network Router
VPN Support	Yes
Firewall	Yes
Dimensions	Varies by model
Processor	Varies by model
Memory	Varies by model
Operating System	Cisco IOS
WAN Ports	Varies by model
LAN Ports	Varies by model
WAN Interfaces	Varies by model
LAN Interfaces	Fast Ethernet or Gigabit Ethernet
