CHAPTER 3

Installing the Chassis

• Rack Mount the Chassis, on page 13

• Ground the Chassis, on page 20

• Connect AC Power to the Chassis, on page 21

• Connect DC Power to the Chassis, on page 23

Rack Mount the Chassis

The chassis can be mounted on a 4-post or a 2-post rack.

• Rack-Mount the Chassis in a 4-Post Rack , on page 13- Contains the procedures for mounting the chassis

in a 4-post rack.

• Rack-Mount the Chassis in a 2-Post Rack, on page 17- Contains procedures for mounting the chassis in

a 2-post rack.

When the Cisco 8200 Series Routers use port side exhaust fans and power supplies, the maximum temperature

is reduced by 5 degrees C (for example, 35 degrees C at sea level or 30 degrees C at 1500 meters).

Note

Rack-Mount the Chassis in a 4-Post Rack

This section describes how to install the router in a 4-post rack.

If the rack is on wheels, ensure that the brakes are engaged or that the rack is otherwise stabilized.

Caution

The following table lists the items that are contained in the rack-mount kit.

Table 2: Rack-Mount Kit

Part DescriptionQuantity

Rack-mount brackets2
