Cisco 8201 Hardware Installation Guide

CONTENTS
Cisco 8200 Series Routers Overview 1
CHAPTER 1
Cisco 8200 Series Routers 1
Prepare for Installation 3
CHAPTER 2
Safety Guidelines 3
Compliance and Safety Information 4
Laser Safety 4
Energy Hazard 4
Preventing Electrostatic Discharge Damage 5
Cautions and Regulatory Compliance Statements for NEBS 5
Installation Guidelines 6
Procure Tools and Equipment 6
Accessory Kit 7
Prepare Your Location 7
Prepare Yourself 8
Prepare Rack for Chassis Installation 9
Clearance Requirements 10
Installing the Chassis 13
CHAPTER 3
Rack Mount the Chassis 13
Rack-Mount the Chassis in a 4-Post Rack 13
Rack-Mount the Chassis in a 2-Post Rack 17
Ground the Chassis 20
Connect AC Power to the Chassis 21
Connect DC Power to the Chassis 23
Hardware Installation Guide for Cisco 8200 Series Routers
iii

Cisco 8201 Specifications

General

Product Name	Cisco 8201
Category	Network Router
Rack Units	1 RU
Operating System	Cisco IOS XR
Product Series	Cisco 8000 Series
Memory	64 GB
Operating Temperature	32 to 104°F (0 to 40°C)
Humidity	5% to 85% non-condensing
Power Supply	AC or DC
Redundancy	Power supplies, fans
Dimensions	1.72 x 17.3 x 22.1 in
