CHAPTER 5
Replace Chassis Components
Replace Fan Modules, on page 37
Replace Power Supply, on page 39
Replace Fan Modules
The fan module is designed to be removed and replaced while the system is operating without presenting an
electrical hazard or damage to the system. Please keep the replacement fan modules ready prior to attempting
this task.
The routers support FAN-1RU-PI (port-side intake airflow) and FAN-1RU-PE (port-side exhaust airflow)
fan modules.
Note
The airflow direction must be the same for all power supply and fan modules in the chassis.
Note
Step 1 To remove a fan module, follow these steps:
a) Press two latches on the fan module and grasp the handle of fan module.
Hardware Installation Guide for Cisco 8200 Series Routers
37
