Cisco Aironet 1815m - Page 9

9
Figure 2 Access Point Ports and Mode Button
Figure 3 AIR-AP-BRACKET-8
1
RJ45 console port
2
PoE-In port (Ethernet Uplink port)
3
Mode button.
For information on how to use the Mode button, see “Using the Mode Button” section on
page 20.
354953
1 2 3
354954
