Summary of Server Features
The following table lists a summary of server features.
DescriptionFeature
One rack-unit (1RU) chassisChassis
Up to two CPUs from the Intel Xeon Processor Scalable Family.
This includes CPUs from the following series:
• Intel Xeon Bronze 3XXX Processors
• Intel Xeon Silver 4XXX Processors
• Intel Xeon Gold 5XXX Processors
• Intel Xeon Gold 6XXX Processors
• Intel Xeon Platinum 8XXX Processors
Central Processor
24 DDR4 DIMM sockets on the motherboard (12 each CPU)Memory
Multi-bit error protection is supportedMulti-bit error protection
BMC, running Cisco Integrated Management Controller (Cisco
IMC) firmware.
Depending on your Cisco IMC settings, Cisco IMC can be
accessed through the 1-Gb dedicated management port, the
1-Gb/10-Gb Ethernet LAN ports, or a Cisco virtual interface card.
Baseboard management
Rear panel:
• One 1-Gb Ethernet dedicated management port (RJ-45
connector)
• Two 1-Gb/10-Gb BASE-T Ethernet LAN ports (RJ-45
connectors)
The dual LAN ports can support 1 Gbps and 10 Gbps,
depending on the link partner capability.
• One RS-232 serial port (RJ-45 connector)
• One VGA video connector port (DB-15 connector)
• Two USB 3.0 ports
Front panel:
• One front-panel keyboard/video/mouse (KVM) connector
that is used with the KVM cable, which provides two USB
2.0, one VGA, and one DB-9 serial connector.
Network and management I/O
Cisco APIC M3/L3 Server Installation and Service Guide
5
Overview
Summary of Server Features
