What to do next
This completes the steps for removing the Cisco ASR1000-RP2 DIMMs from the module.
Replacing the Cisco ASR1000-RP2 DIMMs
This section lists the steps to replace the Cisco ASR1000-RP2 DIMMs.
SUMMARY STEPS
1. Place the route processor on an antistatic mat or pad and ensure that you are wearing an antistatic device,
such as a wrist strap.
2. Position the route processor so that the faceplate is toward you and the edge connector is away from you.
3. Remove the new DIMM from the antistatic bag.
4. Hold the DIMM component-side up, with the connector edge (the metal fingers) closest to you. Hold the
ends of the DIMM between your thumb and forefinger. See the following figure.
5. Tilt the DIMM to approximately the same angle as the socket and insert the connector edge into the socket.
Note the two notches (keys) on the connector edge of the DIMM. These keys are intended to ensure correct
orientation of the DIMM in the socket.
6. Note the orientation of the socket key on the DIMM and the DIMM socket and gently push the DIMM
into the socket until the lever is flush against the side of the DIMM socket, and the DIMM edge connector
is fully inserted. If necessary, rock the DIMM gently back and forth to seat it properly. The following
figure shows how to install the DIMM in the socket.
7. When the DIMM is installed, check that the release lever is flush against the side of the DIMM socket.
If it is not, the DIMM might not be seated properly. If the DIMM appears misaligned, carefully remove
it according to the removal procedure and then reseat it in the socket. Push the DIMM firmly back into
the socket until the release lever is flush against the side of the DIMM socket.
8. Repeat Step 3 through Step 7 for the remaining DIMMs.
9. Replace the Cisco ASR1000-RP2.
DETAILED STEPS
Step 1 Place the route processor on an antistatic mat or pad and ensure that you are wearing an antistatic device, such as a wrist
strap.
Step 2 Position the route processor so that the faceplate is toward you and the edge connector is away from you.
DIMMs are sensitive components that can be shorted by mishandling; they are susceptible to ESD damage.
Handle DIMMs by the edges only and avoid touching the pins.
Caution
Step 3 Remove the new DIMM from the antistatic bag.
Step 4 Hold the DIMM component-side up, with the connector edge (the metal fingers) closest to you. Hold the ends of the
DIMM between your thumb and forefinger. See the following figure.
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
28
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Replacing the Cisco ASR1000-RP2 DIMMs
