2-5
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation and Initial Configuration Guide
OL-13208-01
Chapter 2 Cisco ASR 1000 Series Routers Components
Cisco ASR 1000 Series Route Processor 1
Table 2-2 lists the Cisco ASR 1000 Series RP1 connectors and description.
The Cisco ASR 1000 Series RP1 meets the following requirements:
Supports up to 4GB of ECC-protected memory with single-bit error correction and multi-bit error
detection
Supports On-board Failure Logging (OBFL) with 2MB of memory
Supports the Cisco ASR 1000 Series Router system architecture, midplane, and the Cisco ASR 1006
Router
Enhanced Serdes Interconnect (ESI) at 11.5 G bps.
Gigibit Ethernet switches for EOBC communication and boot-up of the Cisco ASR 1000 Series SPA
Interface (SIP) and Cisco ASR 1000 Series Embedded Services Processor.
Runs Cisco IOS network control plane (routing protocol, connections setup)
Cisco IOS punt packet forwarding
Active/Standby Cisco ASR 1000 Series Route Processor 1 and Cisco ASR 1000 Series Embedded
Services Processor selection
12 LINK 10/100/1000 RJ-45
Interface LED
Solid Green Link with no activity.
Flashing Green Link with activity.
Off No link.
* The type of alarm triggered is associated with the driver itself. For example, environmental alarms are tied to our
environmental code, SONET alarms are tied to the sonet code, ENET to Ethernet.
Table 2-1 Cisco ASR 1000 Series Route Processor 1 LEDs (continued)
No. LED Label LED Color —State Behavior Description
Table 2-2 Cisco ASR 1000 Series RP1 Connectors
No. Label Type Description
1 ACO Alarm cutoff switch. When you press this button, an interrupt is
generated informing software that the
audible alarm relays will be disabled. This
interrupt generates to both processors.
2 0 USB connector 0 Side-by-side USB connector used with
memory sticks or smart cards for secure key
distribution
3 1 USB connector 1 Side-by-side USB connector used with
memory sticks or smart cards for secure key
distribution
4 BITS RJ45 connector Indicates BITS timing reference.
5 MGMT
ETHERNET
One RJ-45 jack for
copper Ethernet
Management Port
The route processor has an ENET port with
a RJ-45 connector to attach a management
device or network for network management.
6 CON One RJ-45 for CON Console port used to connect to a terminal.
7 AUX One RJ-45 for AUX Auxiliary port used for remote management
purposes.
