2-7
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation and Initial Configuration Guide
OL-13208-01
Chapter 2 Cisco ASR 1000 Series Routers Components
Cisco ASR 1000 Series Route Processor 1
Table 2-3 lists the Cisco embedded ASR1000-RP1 LEDs and behaviors.
Table 2-4 lists the Cisco embedded ASR1000-RP1 connectors and description.
Table 2-3 Cisco Embedded ASR1000-RP1 LEDs
LED Label LED Color —State Behavior Description
PWR Power Green All power requirements are within
specification
STAT System status Green Cisco IOS has successfully booted.
Yellow BootROM has successfully loaded.
Red System failure.
MIN Minor Amber Minor alarm indicator.
MAJ Major Red Major alarm indicator.
CRIT Critical Red Critical alarm indicator.
BOOT EUSB0 FLASH
(BootDisk
Flashing Green Active indicator.
Off No activity.
CARRIER Off Out of service or not configured.
Green In frame and working properly.
Amber Fault or loop condition.
LINK 10/100 /1000 RJ-45
Interface LED
Green Link with no activity.
Flashing Green Link with activity.
Off No link.
4 LEDs Built-in SPA SFP
port status
Off Port is not enabled.
Amber Port enabled but there is a problem with the
Ethernet link.
Green Port enabled, valid Ethernet link
PWR SIP card power Green All SIP10 requirements are within specifi-
cation.
STAT SIP card status Green Only when the SPA drivers have started and
are running and all critical processes are
running
Yellow When ROMMON is running and during the
download and boot of the operating system
Red A fault is detected or the card is powering
up.
Table 2-4 Cisco Embedded ASR1000-RP1 Connectors
Label Type Description
BITS RJ45 connector Indicates BITS timing reference.
MGMT One RJ-45 jack for
copper Ethernet
Management Ethernet
Port
The route processor has an ENET port with a RJ-45
connector to attach a management device or network
for network management.
