Requirement
Auditable
Events
Additional Audit
Record Contents
Sample Record
Session
establishment
with peer
Entire packet
contents of packets
transmitted/receive
d during session
establishment
Jun 20 07:42:26.823: ISAKMP (0): received packet
from 100.1.1.5 dport 500 sport 500 Global (N) NEW
SA
Jun 20 07:42:26.823: ISAKMP: Created a peer struct
for 100.1.1.5, peer port 500
Jun 20 07:42:26.823: ISAKMP: New peer created
peer = 0x89C3879C peer_handle = 0x8000000C
Jun 20 07:42:26.823: ISAKMP: Locking peer struct
0x89C3879C, refcount 1 for
crypto_isakmp_process_block
Jun 20 07:42:26.823: ISAKMP: local port 500,
remote port 500
Jun 20 07:42:26.823: ISAKMP:(0):insert sa
successfully sa = 8C1C1FD4
Jun 20 07:42:26.823: ISAKMP:(0):Input =
IKE_MESG_FROM_PEER, IKE_MM_EXCH
Jun 20 07:42:26.823: ISAKMP:(0):Old State =
IKE_READY New State
= IKE_R_MM1 …
Jun 20 07:42:26.823: ISAKMP:(0):found peer pre-
shared key matching 100.1.1.5
Jun 20 07:42:26.823: ISAKMP:(0): local preshared
key found
Jun 20 07:42:26.823: ISAKMP : Scanning profiles
for xauth ...
Jun 20 07:42:26.823: ISAKMP:(0):Checking
ISAKMP transform 1 against priority 1 policy
Jun 20 07:42:26.827: ISAKMP: encryption AES-
CBC
Jun 20 07:42:26.827: ISAKMP: keylength of 128
Jun 20 07:42:26.827: ISAKMP: hash SHA
Jun 20 07:42:26.827: ISAKMP: default group 14
Jun 20 07:42:26.827: ISAKMP: auth pre-share…
Jun 20 07:42:26.843: ISAKMP (0): received packet
from 100.1.1.5 dport 500 sport 500 Global (R)
MM_SA_SETUP
Jun 20 07:42:26.843: ISAKMP:(0):Input =
IKE_MESG_FROM_PEER, IKE_MM_EXCH

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
