Cisco ASR 1002 Replacing

3. Place the Cisco ASR1000-ESP module on an antistatic surface with its printed circuit board components
facing upward or in a static shielding bag.
DETAILED STEPS
Step 1 Slip on the ESD-preventive wrist strap that was included in the accessory kit. Loosen the captive screws on the Cisco
ASR 1000 Series Embedded Services Processor.
Step 2 Using the handles on both sides of the module, with two hands gently slide the Cisco ASR 1000 Series Embedded Services
Processor (ESP5, ESP10, ESP20, ESP40) out of the chassis slot.
Handle the Cisco ASR1000-ESP5, Cisco ASR1000-ESP10, Cisco ASR1000-ESP20, or Cisco ASR1000-ESP40
by the carrier edges only; never touch the printed circuit board components or connector pins.
Note
Step 3 Place the Cisco ASR1000-ESP module on an antistatic surface with its printed circuit board components facing upward
or in a static shielding bag.
What to do next
You have completed the removal procedure for the Cisco ASR 1000 Series Embedded Services Processor.
from a Cisco ASR1000-ESP.
Replacing the Cisco ASR1000-ESP
To replace the Cisco ASR 1000 Series Embedded Services Processor in the Cisco ASR 1000 Series Router,
follow this procedure:
SUMMARY STEPS
1. Attach an ESD-preventive wrist strap between you and an unfinished chassis surface.
2. Remove the new Cisco ASR1000-ESP from its static shielding bag.
3. Using both hands, grasp the Cisco ASR1000-ESP by its metal carrier edges and orient the it so that its
printed circuit board components are upward.
4. Align the left and right edges of the Cisco ASR1000-ESP printed circuit board between the Cisco
ASR1000-ESP slot guides.
5. Gently slide the Cisco ASR1000-ESP all the way into its chassis slot until you feel the connectors seat
with the router midplane.
6. Seat the Cisco ASR1000-ESP in the router midplane by tightening its captive installation screws with a
number 2 Phillips or a 3/16-inch flat-blade screwdriver.
DETAILED STEPS
Step 1 Attach an ESD-preventive wrist strap between you and an unfinished chassis surface.
Step 2 Remove the new Cisco ASR1000-ESP from its static shielding bag.
Step 3 Using both hands, grasp the Cisco ASR1000-ESP by its metal carrier edges and orient the it so that its printed circuit
board components are upward.
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
52
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Replacing the Cisco ASR1000-ESP

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
