Cisco ASR 1002 Replacing

*For information about the DB-25 alarm
connector, how it works, and Cisco ASR 1000
route processor LEDs, see the xref “How Cisco
ASR1000-RP Alarm Monitoring Works” section
on page 2-20.
Note: Shielded cables must be used to connect to
the DB-25 alarm connector on both the AC and
DC power supplies, in order to comply with
FCC/EN55022/CISPR22 Class A emissions
requirements.
Removing the DC Power Supply from the Cisco ASR 1004 Router
Before you can remove a DC power supply from the Cisco ASR 1004 Router, you must remove power from
the power supply. Follow these steps to remove power and the DC power supply from the chassis.
SUMMARY STEPS
1. Make certain that the chassis ground is connected before you begin removing the DC power supply.
2. Switch the power supply circuit breaker switch to Off (O).
3. Locate the terminal block on the rear of the chassis on the power supply. The following figure shows the
DC power supply terminal block.
4. Remove the slotted plastic cover from the terminal block.
5. Locate the power supply ground stud (see xref fig). Remove the ground (GND) cable from the DC power
supply.
6. Loosen and remove the Kepnut screw, washer, and ground lug in that order.
7. Loosen the captive screws on the DC power supply.
8. Grasping the power supply handles, pull the power supply from the chassis.
9. Replace the DC power supply within five minutes.
DETAILED STEPS
Step 1 Make certain that the chassis ground is connected before you begin removing the DC power supply.
Step 2 Switch the power supply circuit breaker switch to Off (O).
Step 3 Locate the terminal block on the rear of the chassis on the power supply. The following figure shows the DC power
supply terminal block.
Step 4 Remove the slotted plastic cover from the terminal block.
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
75
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing the DC Power Supply from the Cisco ASR 1004 Router

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
