Cisco ASR 9000v

Figure 114: Installing the Cisco ASR 9904 Router Chassis in a Standard 2-Post Rack
Six screws per side (minimum) to attach the router
chassis to the rack.
1
The figure below shows the orientation of the Cisco ASR 9906 Router chassis to the rack posts and components
used in the installation.
Cisco ASR 9000 Series Aggregation Services Router Hardware Installation Guide
108
Unpacking and Installing the Chassis
Installing the Chassis in a 2-Post Rack
