Figure 156: Securing the Cisco ASR 9904 Router Chassis Side Baffles to the Air Deflectors (Rear View)
Step 6 Use six 12-24 screws to fasten each side of the chassis to the 23-inch rack. Torque each of the six screws to
41 in-lbs. (Figure 157: Mounting the Cisco ASR 9904 Router Chassis in a 23-Inch Rack, on page 149).
Figure 157: Mounting the Cisco ASR 9904 Router Chassis in a 23-Inch Rack
Step 7 Tighten the remaining loose screws to complete the installation. Torque the 8-32 screws to 18 in-lb and the
12-24 screws to 41 in-lb.
Figure 158: Cisco ASR 9904 Router Chassis with Air Baffle in 2-Post 23-Inch Rack, on page 150 shows the
router chassis with the air baffle installed in a 2-post 23-inch rack.
Cisco ASR 9000 Series Aggregation Services Router Hardware Installation Guide
149
Unpacking and Installing the Chassis
Installing Optional Air Baffles on the Cisco ASR 9904 Router
