Cisco ASR 9010 Unpacking And Installing

Router Components and Slot NumberingRouter Model Number
• 6 slots.
• Version 3 power system (Figure 25: Cisco ASR 9906 Router Components and Slot Numbering with
Version 3 AC Power System for AC and Figure 26: Cisco ASR 9906 Router Components and Slot
Numbering with Version 3 DC Power System for DC).
• Two RSP cards installed in the two slots (labeled RSP0 and RSP1)
• Four line cards installed in slots LC0 through LC3.
• Up to 5 fabric cards, mounted from rear of the chassis.
Cisco ASR 9906 Router
• 15 slots.
• Version 3 power system (Figure 27: Cisco ASR 9910 Router Components and Slot Numbering with
Version 3 AC Power System , on page 32 for AC and Figure 28: Cisco ASR 9910 Router Components
and Slot Numbering with Version 3 DC Power System , on page 32 for DC).
• Two RSP cards installed in the two slots (labeled RSP0 and RSP1)
• Eight line cards installed in slots LC0 through LC7.
• Up to 5 fabric cards and mounted from rear of the chassis.
Cisco ASR 9910 Router
Figure 20: Cisco ASR 9006 Router Components and Slot Numbering with Version 1 Power System
Unpacking and Installing the Chassis
28
Unpacking and Installing the Chassis
Removing RSP Cards and Line Cards from the Cisco ASR 9006, 9010, 9904, 9906, and 9910 Routers

Cisco ASR 9010 Specifications

General

Chassis	Modular
Rack Units	21 RU
Operating System	Cisco IOS XR
Form Factor	Rack-mountable
Number of Slots	10
Power Supply	AC or DC
Redundancy	Yes
Slots	8 line card slots, 2 route switch processor slots
Memory	16 GB DRAM
Storage	64 GB SSD (Route Processor)
Port Types	Ethernet, OTN
Redundancy Features	Route Processor, Power Supply, Fan Tray
Operating Temperature	32 to 104°F (0 to 40°C)
Humidity	5% to 90% non-condensing
Route Processor	Cisco ASR 9000 Series Route Switch Processor
