Cisco ASR 9010 Unpacking And Installing

Table 2: Router Components and Slot Numbering for the Cisco ASR 9922 Router and Cisco ASR 9912 Router
Router Components and Slot NumberingRouter Model Number
• 22 slots.
• Version 2 or version 3 power system. See Figure 35: Cisco ASR 9922 Router Components and Slot
Numbering with Version 2 DC Power System, on page 39 for version 2 DC and Figure 36: Cisco
ASR 9922 Router Components and Slot Numbering with Version 3 DC Power System, on page 40
for version 3 DC. See Figure 36: Cisco ASR 9922 Router Components and Slot Numbering with
Version 3 DC Power System, on page 40 for version 2 AC and Figure 38: Cisco ASR 9922 Router
Components and Slot Numbering with Version 3 AC Power System, on page 42 for version 3 AC.
• Up to seven FC cards installed between the two RSP cards in the middle cage of the chassis.
• Ten line cards installed in slots 0 through 9 in the top card cage.
• Ten line cards installed upside down in slots 10 through 19 in the bottom card cage.
Cisco ASR 9922 Router
• 12 slots.
• Version 2 or version 3 power system, See Figure 39: Cisco ASR 9912 Router Components and Slot
Numbering with Version 2 DC Power System, on page 43 for version 2 DC or version 3 power
systems (Figure 39: Cisco ASR 9912 Router Components and Slot Numbering with Version 2 DC
Power System, on page 43 for DC and Figure 40: Cisco ASR 9912 Router Components and Slot
Numbering with Version 3 AC Power System, on page 44 for AC).
• Up to seven FC cards installed between the two RP cards above the power trays.
• Ten line cards installed in slots 0 through 9 below the fan trays.
Cisco ASR 9912 Router
Unpacking and Installing the Chassis
38
Unpacking and Installing the Chassis
Removing RP Cards, Fabric Cards, and Line Cards from the Cisco ASR 9922 Router and Cisco ASR 9912 Router

Cisco ASR 9010 Specifications

General

Chassis	Modular
Rack Units	21 RU
Operating System	Cisco IOS XR
Form Factor	Rack-mountable
Number of Slots	10
Power Supply	AC or DC
Redundancy	Yes
Slots	8 line card slots, 2 route switch processor slots
Memory	16 GB DRAM
Storage	64 GB SSD (Route Processor)
Port Types	Ethernet, OTN
Redundancy Features	Route Processor, Power Supply, Fan Tray
Operating Temperature	32 to 104°F (0 to 40°C)
Humidity	5% to 90% non-condensing
Route Processor	Cisco ASR 9000 Series Route Switch Processor
