Cisco ASR 9010 Unpacking And Installing

Figure 58: Installing the Cisco ASR 9910 Router Chassis in a 4-Post Rack
Use screws and four post
rack mount brackets from
four post rack mount
bracket kit for this
installation.
2Use screws to attach the
router chassis to the rack.
1
Unpacking and Installing the Chassis
61
Unpacking and Installing the Chassis
Preparing the 19 Inch 45-RU Rack

Cisco ASR 9010 Specifications

General

Chassis	Modular
Rack Units	21 RU
Operating System	Cisco IOS XR
Form Factor	Rack-mountable
Number of Slots	10
Power Supply	AC or DC
Redundancy	Yes
Slots	8 line card slots, 2 route switch processor slots
Memory	16 GB DRAM
Storage	64 GB SSD (Route Processor)
Port Types	Ethernet, OTN
Redundancy Features	Route Processor, Power Supply, Fan Tray
Operating Temperature	32 to 104°F (0 to 40°C)
Humidity	5% to 90% non-condensing
Route Processor	Cisco ASR 9000 Series Route Switch Processor
