Cisco ASR 9010 Unpacking And Installing

Figure 84: Securing the ASR 9006 Router in a Two-Post 19-Inch Rack
Screws attaching chassis
to plenum
2Screws attaching chassis
to rack
1
Step 9 Install the optional chassis accessories, if desired. See Installing Optional Chassis Accessories on the Cisco
ASR 9006 Router, on page 78.
The figure below shows the air baffle accessory kit and Cisco ASR 9006 Router with its optional accessories
fully installed in a two-post 19-inch rack.
Unpacking and Installing the Chassis
85
Unpacking and Installing the Chassis
Installing Optional Air Baffles on the Cisco ASR 9006 Router

Cisco ASR 9010 Specifications

General

Chassis	Modular
Rack Units	21 RU
Operating System	Cisco IOS XR
Form Factor	Rack-mountable
Number of Slots	10
Power Supply	AC or DC
Redundancy	Yes
Slots	8 line card slots, 2 route switch processor slots
Memory	16 GB DRAM
Storage	64 GB SSD (Route Processor)
Port Types	Ethernet, OTN
Redundancy Features	Route Processor, Power Supply, Fan Tray
Operating Temperature	32 to 104°F (0 to 40°C)
Humidity	5% to 90% non-condensing
Route Processor	Cisco ASR 9000 Series Route Switch Processor
