Clocking

Sync-E Configuration ▀

Cisco ASR 903 Router Design and Deployment Guide▄

OL-30526-01

133

Figure 28. Input Source Options

Here is the diagram for SYNC-E configuration. R1 router has its BITS port connected to external clock source and

then uses SYNC-E to distribute it to other routers.

Figure 29. SYNC-E

ASR903-R2

Loopback10: 10.10.2.2

ASR903-R4

Loopback10: 10.10.4.4

Gi0/1/0

Gi0/1/1

Gi0/1/0Gi0/1/2

Gi0/1/0Gi0/1/1

Gi0/1/4

ASR903-R3

Loopback10: 10.10.3.3

ASR903-R1

Loopback10: 10.10.1.1

Clock Source
