This equipment is suitable for installation in Network Telecommunications Facilities and locations where
the NEC applies. The equipment is suitable for installation as part of the Common Bonding Network
(CBN).
Note
Connect the unit only to DC power source that complies with the safety extra-low voltage (SELV)
requirements in IEC 60950 based safety standards. Statement 1033
Warning
The grounding architecture of this product is DC-isolated (DC-I) for DC-powered products. DC-powered
products have a nominal operating DC voltage of 24V and -48 VDC.
Caution
Before You Begin
When powering the router with DC power, you must ensure that DC power can be conveniently removed
from the unit. The power should not be removed by disconnecting the DC power connector on the unit.
Procedure
SUMMARY STEPS
1.
Fix the connector side to the router.
2.
Ensure that the notch on the connector is aligned with the contact socket on the cable. See Four-pin Power
Connector figure .
3.
Tighten coupling nut fully so that the connector is fastened to the router.
DETAILED STEPS
Step 1
Fix the connector side to the router.
Step 2
Ensure that the notch on the connector is aligned with the contact socket on the cable. See Four-pin Power Connector
figure .
Step 3
Tighten coupling nut fully so that the connector is fastened to the router.
Powering On the Router
After the router is rack mounted, perform these tasks to complete the installation:
•
Power on the router.
•
Connect the front-panel ports. See the Connecting to SFP Modules section, to complete the installation.
Cisco ASR 920-10SZ-PD Aggregation Services Router Hardware Installation Guide
11
Installing the Cisco ASR-920-10SZ-PD Router
