Cisco ASR-920-10SZ-PD User Manual

•
9600 baud
•
8 data bits
•
no parity
•
1 stop-bit
•
no flow control
Connecting a Management Ethernet Cable
It is recommended that you retain the RJ-45 dust caps for the ports (RJ-45, SFP, and USB ports) that are
not used.
Note
When using the Ethernet Management port in the default mode (speed-auto and duplex-auto) the port operates
in the auto-MDI/MDI-X mode. The port automatically provides the correct signal connectivity through the
Auto-MDI/MDI-X feature. The port automatically senses a crossover or straight-through cable and adapts to
it.
However, when the Ethernet Management port is configured to a fixed speed (10, 100, or 1000 Mbps) through
command-line interface (CLI) commands, the port is forced to the MDI mode.
When in a fixed-speed configuration and MDI mode:
•
Use a crossover cable to connect to an MDI port
•
Use a straight-through cable to connect to an MDI-X port
To comply with the Telcordia GR-1089 NEBS standard for electromagnetic compatibility and safety,
connect the Management Ethernet ports only to intra-building or unexposed wiring or cable. The
intrabuilding cable must be shielded and the shield must be grounded at both ends. The intra-building
port(s) of the equipment or subassembly must not be metallically connected to interfaces that connect to
the OSP or its wiring. These interfaces are designed for use as intra-building interfaces only (Type 2 or
Type 4 ports as described in GR-1089-CORE) and require isolation from the exposed OSP cabling. The
addition of Primary Protectors is not sufficient protection in order to connect these interfaces metallically
to OSP wiring.
Note
Installing and Removing SFP and SFP+ Modules
The Cisco ASR-920-10SZ-PD Router supports a variety of SFP and SFP+ modules, including optical and
Ethernet modules. For information on how to install and remove SFP and SFP+ modules, see the documentation
for the SFP or SFP+ module at:
http://www.cisco.com/en/US/partner/products/hw/modules/ps5455/prod_installation_guides_list.html
Cisco ASR 920-10SZ-PD Aggregation Services Router Hardware Installation Guide
26
Installing the Cisco ASR-920-10SZ-PD Router
Connecting a Management Ethernet Cable
