Cisco ASR-920-24TZ-M Installation Guide

5-4
Cisco ASR-920-24SZ-IM, ASR-920-24SZ-M, ASR-920-24TZ-M Aggregation Services Router Hardware Installation Guide
Chapter 5 Troubleshooting
Pinouts
USB Console Port Pinouts
Table 5-6 summarizes the USB console port pinouts.
Note The USB console port +5VDC is input, and operates as an USB peripheral device.
USB Flash or MEM Port Pinouts
Table 5-7 summarizes the USB flash or MEM port pinouts.
Note USB TYPE-A receptacle is used.
4TRP2+
5TRP2-
6TRP1-
7TRP3+
8TRP3-
Table 5-5 Fan Alarm Port Pinout
Pin Signal Name
Table 5-6 Single USB Console Port Pinouts
Pin Signal Name Description
A1 Vcc +5VDC
A2 D- Data -
A3 D+ Data +
A4 Gnd Ground
Table 5-7 Single USB Flash or MEM Port Pinouts
Pin Signal Name Description
A1 Vcc +5VDC (500mA)
A2 D- Data -
A3 D+ Data +
A4 Gnd Ground
