Cisco C1101-4P Hardware Installation Guide

Control SourceDescriptionLED ColorPort
Bezel sideOff— No tunnel.Green
VPN OK
Steady On— At least one
tunnel is up.
Bezel sideNo LEDs On—No serviceGreen and Amber
LTE RSSI/mode
1 LED On— RSSI is
under -100dBm.
2 LEDs On— Low RSSI,
-99dbm <> -90dBm.
3 LEDs On— Medium
RSSI -89dBm <>
-70dBm.
4 LEDs On— High RSSI,
> -69dBm.
Green— LTE
Amber— 3G
Bezel sideOff: GPS not configuredGreen
GPS
On: GPS configured
Blink: GPS acquiring
Bezel sideGreen— Normal
operating condition with
at least one wireless client
association.
Green, Red, and Amber
WLAN
Red—Ethernet link is not
operational or ethernet
failure.
Amber—Software
upgrade is in progress.
I/O sideOff— No linkGreen
Ethernet switch GE LAN
ports, non-PoE
Steady On— Link
Blink— TXD/RXD data
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
17
Overview of Cisco 1000 Series Integrated Services Routers
LED Indicators

Cisco C1101-4P Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	-
WLAN data transfer rate (max)	- Mbit/s
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
Security algorithms	AES, WPA2
Product type	Tabletop router
Product color	Gray
Country of origin	China
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	30 W
Internal memory	4000 MB
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	0 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
Package depth	333.502 mm
Package width	254 mm
Package height	177.8 mm
Package weight	3083.9 g
