Cisco C1101-4P Hardware Installation Guide

Control SourceDescriptionLED ColorPort
I/O sideOff— No link, no device
powered, PD denied
power, power delivery
fault PoE administratively
disabled.
Green steady on— link; if
PoE device, power is
enabled.
Green Blink— TXD/RXD
data
Amber - PoE fault
Green and Amber
Ethernet switch GE LAN
ports, with PoE
I/O sideGreen steady on— -53.5V
PoE power supply
connected and all powered
port operating normally.
GreenPoE OK
Off — No -53.5V PoE
power supply connected
to router.
I/O sideOff— No linkGreen
GE WAN ports
Steady on— link
Blink— TXD/RXD data
I/O sideOff— ShutGreen
DSL CD
Green blink— Training,
or no shut and cable
disconnected.
Green steady on—
Trained
I/O sideOff— No data activityGreen
DSL data
Green blink— TX/RX
Data
I/O sideGreen on— console
enabled.
Green
Console
I/O sideOff— No USB device
discovered.
GreenUSB console
On— USB device
discovered.
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
18
Overview of Cisco 1000 Series Integrated Services Routers
LED Indicators

Cisco C1101-4P Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	-
WLAN data transfer rate (max)	- Mbit/s
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
Security algorithms	AES, WPA2
Product type	Tabletop router
Product color	Gray
Country of origin	China
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	30 W
Internal memory	4000 MB
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	0 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
Package depth	333.502 mm
Package width	254 mm
Package height	177.8 mm
Package weight	3083.9 g
