Cisco C1121 8PLTEPW Series - LED Indicators

Figure 5: C1101-4PLTEP-Bezel View
Non-illuminated Cisco logo1
Figure 6: C1101-4PLTEP - I/O View
4-pin Power Connector2Power Switch1
LAN:0-44Reset Button3
Micro-USB console Port6GE WAN5
Grounding8Pluggable7
Kensington Lock Slot9
Figure 7: C1109-4PLTE2P - Bezel View
Non-illuminated Cisco logo1
Main and Diversity Antenna2
