Key-hole slots
Horizontal spacing: 3.100in (78.74mm)
Vertical spacing: 5.758inin (146.25mm)
1
Figure 43: Wall mount using key-hole slots - C1126-8PLTEP
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
42
Install and Connect the Router
Wall Mount Using Key-hole Slots
