Figure 52: Console Adapter for C1101-4PLTEP
Micro USB to RJ45 console adapter1.
Figure 53: Console Adapter for C1127X-8PLTEP
Micro USB to RJ45 console adapter1.
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
50
Install and Connect the Router
Connect the Router to a Console
