3-35

Cisco UCS C240 M4 Server Installation and Service Guide

OL-32474-01

Chapter 3 Maintaining the Server

Installing or Replacing Server Components

Figure 3-19 SCPM (RAID Backup Unit) Mounting Point and Cable Path

1 SCPM mounting point on removable air baffle

(air baffle not shown)

2 SCPM cable routing path (the red line)

352962

FAN 05

FAN 04

FAN 0 3

FAN 02

FAN 01

CPU 1

CPU 2

SD1

SD2

Riser 2

Riser 1
