A-4
Cisco UCS C240 M4 Server Installation and Service Guide
OL-32474-01
Appendix A Server Specifications
Power Specifications
930 W DC Power Supply
Table A-5 lists the specifications for each 930 W DC power supply
(Cisco part number UCSC-PSU-930WDC=).
Power supply output voltage 12 VDC
Power supply standby voltage 12 VDC
Efficiency rating Climate Savers Platinum Efficiency (80Plus Platinum
certified)
Form factor RSP1
Input connector IEC320 C14
Table A-4 1400 W Power Supply Specifications
Description Specification
Table A-5 930 W DC Power Supply Specifications
Description Specification
DC input voltage range Nominal range: –48 to –60 VDC nominal
(Range: –40 to –60 VDC)
Maximum DC input current 23 A at –48 VDC
Maximum input W 1104 W
Maximum output power per PSU 930 W
Maximum inrush current 35 A (sub-cycle duration)
Maximum hold-up time 8 ms at 930 W
Power supply output voltage 12 VDC
Power supply standby voltage 12 VDC
Efficiency rating > 92% at 50% load
Form factor RSP1
Input connector Removable connector block UCSC-CONN-930WDC=

Cisco c240 Specifications

General

Product Type	Rack Server
Memory	Up to 3TB DDR4
Network Interface	4 x 1GbE or 2 x 10GbE
Storage	Up to 24 x 2.5" or 12 x 3.5"
Remote Management	Cisco Integrated Management Controller (CIMC)
Operating System Support	VMware, Microsoft, Red Hat
Form Factor	2U Rack
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
