Cisco c240 User Manual

A-3
Cisco UCS C240 M4 Server Installation and Service Guide
OL-32474-01
Appendix A Server Specifications
Power Specifications
1200 W AC Power Supply
Table A-3 lists the specifications for each 1200 W AC power supply
(Cisco part number UCSC-PSU2V2-1200W=).
1400 W AC Power Supply
Table A-2 lists the specifications for each 1400 W AC power supply
(Cisco part number UCSC-PSU2-1400=).
Table A-3 Power Supply Specifications
Description Specification
AC input voltage Nominal range: 100–120 VAC, 200–240 VAC
(Range: 90–132 VAC, 180–264 VAC)
AC input frequency Nominal range: 50 to 60Hz
(Range: 47–63 Hz)
Maximum AC input current 11 A at 100 VAC
7 A at 200 VAC
Maximum input volt-amperes 1456 VA
Maximum output power per PSU 800 W at 100–120 VAC
1200 W at 200–240 VAC
Maximum inrush current 35 A (sub-cycle duration)
Maximum hold-up time 12 ms at 1200 W
Power supply output voltage 12 VDC
Power supply standby voltage 12 VDC
Efficiency rating Climate Savers Platinum Efficiency (80Plus Platinum certified)
Form factor RSP1
Input connector IEC320 C14
Table A-4 1400 W Power Supply Specifications
Description Specification
AC input voltage Nominal range: 200–240 VAC
(Range: 180–264 VAC)
AC input frequency Nominal range: 50 to 60Hz
(Range: 47–63 Hz)
Maximum AC input current 8.5 A at 200 VAC
Maximum input volt-amperes 1700 VA
Maximum output power per PSU 1400 W at 200–240 VAC
Maximum inrush current 35 A (sub-cycle duration)
Maximum hold-up time 12 ms at 1200 W

Cisco c240 Specifications

General

Product Type	Rack Server
Memory	Up to 3TB DDR4
Network Interface	4 x 1GbE or 2 x 10GbE
Storage	Up to 24 x 2.5" or 12 x 3.5"
Remote Management	Cisco Integrated Management Controller (CIMC)
Operating System Support	VMware, Microsoft, Red Hat
Form Factor	2U Rack
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
