Mounting the Switch
The following table explains the different mounting options supported by C9200CX compact switches.
Table 4: Mounting Options
Accessories UsedMounting Method
• Mounting using the Mounting Tray and Screws
• Mounting using the Mounting Tray and Magnet
Wall mount
• Mounting the Switch Using Rack Mount
Brackets
Rack mount
• Mounting Under a Desk or a Shelf
• Mounting using the Mounting Tray and Magnet
Shelf or top/bottom of a desk mount
• Mounting the Switch on a DIN RailDin rail mount
Mounting on a Desk or Shelf Without Mounting Screws
Procedure
Step 1 Locate the adhesive strip with the rubber feet in the accessory kit.
Step 2 Remove the four rubber feet from the adhesive strip, and attach them to the locations indicated at the bottom
of the unit. This prevents the switch from sliding on the desk or shelf.
Cisco Catalyst 9200CX Compact Series Switches Hardware Installation Guide
23
Installing a Compact Switch
Mounting the Switch
To Next Page
