Cisco C9200L-24T-4X User Manual

Figure 37: Site Profile - Access Switches
Figure 38: Site Profile - Access Switches (with Routed Access)
Table 13: Default Configuration Loaded with Each Site Profile (Distribution Switches)
Redundant Distribution
Switch (Port Channel
Peer and Downlink)
Single Distribution
Switch (Single Port
Channel Downlink)
Single Distribution
Switch (Single Downlink)
Setting
The hostname or device
name you provided as part
of Quick Setup
The hostname or device
name you provided as part
of Quick Setup
The hostname or device
name you provided as part
of Quick Setup
Hostname
RPVST+RPVST+RPVST+Spanning Tree Mode
Mode TransparentMode TransparentMode TransparentVTP
EnabledEnabledEnabledUDLD
Recovery mode set to
Auto
Recovery mode set to
Auto
Recovery mode set to
Auto
Error Disable Recovery
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
56
Configuring the Switch
Configuring Your Device Based on a Site Profile

Cisco C9200L-24T-4X Specifications

General

Model	C9200L-24T-4X
Device Type	Switch
Enclosure Type	Rack-mountable
Subtype	Gigabit Ethernet
Switching Capacity	128 Gbps
Forwarding Rate	95.23 Mpps
DRAM	4 GB
Flash Memory	4 GB
Power Device	Internal power supply
Ports	24 x 10/100/1000
Uplink Interfaces	4 x 10 Gigabit SFP+
MAC Address Table Size	16, 000 entries
Jumbo Frame Support	9198 bytes
Routing Protocol	OSPF, BGP, EIGRP, RIP
Remote Management Protocol	SNMP 1, SNMP 2, SNMP 3, RMON, SSH, Telnet, HTTP, HTTPS
Features	VLAN support, Quality of Service (QoS), ACL support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3ae
Voltage Required	AC 120/230 V (50 - 60 Hz)
Stacking	Stackable
Operating Temperature	32 to 104°F (0 to 40°C)
