Cisco C9200L-24T-4X User Manual

CHAPTER 1
Product Overview
• Switch Models, on page 1
• Front Panel Components, on page 2
• Rear Panel, on page 6
• Network Configurations, on page 11
Switch Models
The Cisco Catalyst 9200 Series switches have four modular (C9200) and eight fixed (C9200L) switch models.
The following tables describe all the available Cisco Catalyst 9200 Series switches and the features supported.
Table 1: C9200L Switch Models and Descriptions
DescriptionSwitch Model
Stackable 24x1G PoE+ ports; 4x1G fixed uplink ports; 2 power
supply slots; 2 fixed fans; supports StackWise-80.
C9200L-24P-4G
Stackable 24x1G PoE+ ports; 4x10G fixed uplink ports; 2 power
supply slots; 2 fixed fans; supports StackWise-80.
C9200L-24P-4X
Stackable 24x1G ports; 4x1G fixed uplink ports; 2 power supply
slots; 2 fixed fans; supports StackWise-80.
C9200L-24T-4G
Stackable 24x1G ports; 4x10G fixed uplink ports; 2 power supply
slots; 2 fixed fans; supports StackWise-80.
C9200L-24T-4X
Stackable 48x1G PoE+ ports; 4x1G fixed uplink ports; 2 power
supply slots; 2 fixed fans; supports StackWise-80.
C9200L-48P-4G
Stackable 48x1G PoE+ ports; 4x10G fixed uplink ports; 2 power
supply slots; 2 fixed fans; supports StackWise-80.
C9200L-48P-4X
Stackable 48x1G ports; 4x1G fixed uplink ports; 2 power supply
slots; 2 fixed fans; supports StackWise-80.
C9200L-48T-4G
Stackable 48x1G PoE+ ports; 4x10G fixed uplink ports; 2 power
supply slots; 2 fixed fans; supports StackWise-80.
C9200L-48T-4X
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
1

Cisco C9200L-24T-4X Specifications

General

Model	C9200L-24T-4X
Device Type	Switch
Enclosure Type	Rack-mountable
Subtype	Gigabit Ethernet
Switching Capacity	128 Gbps
Forwarding Rate	95.23 Mpps
DRAM	4 GB
Flash Memory	4 GB
Power Device	Internal power supply
Ports	24 x 10/100/1000
Uplink Interfaces	4 x 10 Gigabit SFP+
MAC Address Table Size	16, 000 entries
Jumbo Frame Support	9198 bytes
Routing Protocol	OSPF, BGP, EIGRP, RIP
Remote Management Protocol	SNMP 1, SNMP 2, SNMP 3, RMON, SSH, Telnet, HTTP, HTTPS
Features	VLAN support, Quality of Service (QoS), ACL support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3ae
Voltage Required	AC 120/230 V (50 - 60 Hz)
Stacking	Stackable
Operating Temperature	32 to 104°F (0 to 40°C)
