Figure 39: Site Profile - Distribution Switches
Figure 40: Site Profile - Distribution Switches (with Routed Access)
Table 14: Default Configuration Loaded with Each Site Profile (Core Switches)
Standalone Collapsed Core Switch
(with ECMP Peer and Port Channel
Downlink)
Standalone Core Switch (with
ECMP Peers)
Setting
The hostname or device name you
provided as part of Quick Setup
The hostname or device name you
provided as part of Quick Setup
Hostname
EnabledEnabledUDLD
Recovery mode set to AutoRecovery mode set to AutoError Disable Recovery
Source Destination IPSource Destination IPPort Channel Load Balance
Version 2Version 2SSH
EnabledEnabledSCP
EnabledEnabledVTY Access to Switch
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
58
Configuring the Switch
Configuring Your Device Based on a Site Profile

Cisco C9200L-24T-4X Specifications

General

Model	C9200L-24T-4X
Device Type	Switch
Enclosure Type	Rack-mountable
Subtype	Gigabit Ethernet
Switching Capacity	128 Gbps
Forwarding Rate	95.23 Mpps
DRAM	4 GB
Flash Memory	4 GB
Power Device	Internal power supply
Ports	24 x 10/100/1000
Uplink Interfaces	4 x 10 Gigabit SFP+
MAC Address Table Size	16, 000 entries
Jumbo Frame Support	9198 bytes
Routing Protocol	OSPF, BGP, EIGRP, RIP
Remote Management Protocol	SNMP 1, SNMP 2, SNMP 3, RMON, SSH, Telnet, HTTP, HTTPS
Features	VLAN support, Quality of Service (QoS), ACL support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3ae
Voltage Required	AC 120/230 V (50 - 60 Hz)
Stacking	Stackable
Operating Temperature	32 to 104°F (0 to 40°C)
