Installing and Connecting the Router
Connectors and Cabling for the 8-Port Asynchronous/ Synchronous RS-232 GRWIC
RS-232 RJ-45 Cable Pinouts
Table 14 on page 54 shows the pinouts for the CAB-QUAD-ASYNC-M (High Density 4-port EIA-232 to Male RJ45, DTE)
and CAB-QUAD-ASYNC-F RJ-45 (High Density 4-port EIA-232 to Female RJ45, 18 inches, DTE) cables:
7 RTS Output Request to Send. Raised by DCE when it wishes to send. Expects CTS from DTE.
8 CTS Input Clear to Send. Raised by DCE in response to RTS from DTE.
9— —
Table 13 Pinouts for CAB-9AS-M (Male DB-9) (continued)
Pin Signal Direction Description
Table 14 Pinouts for the Male and Female RJ-45 Cables
Pin Signal Description
1 RTS Request to Send
2 — Unassigned
3TXD Transmit Data
4 SGND Signal Ground
5GRNDGround
6 RXD Transmit Data
7 — Unassigned
8CTS Clear to Send
