Cisco Firepower 4110 Hardware Installation Guide

Green OK LED2Amber FAIL LED1
The following table describes the power module supply LEDs and their states.
Table 9: Power Supply Module LEDs
Green LED (OK Status)Amber LED (Fail
Status)
OffOffNo power to all power supplies
OffOnPower supply module failure
Includes overvoltage, overcurrent, overtemperature,
and fan failure
Off1 Hz flashingPower supply module warning events
Power supply continues to operate.
With high temperature, high power, and slow fan
1 Hz flashingOffPower is present.
3.3 VSB on (power supply module off)
OnOffPower supply module is OK and on.
Fan Modules
The Firepower 4100 requires six fan modules, which are hot-swappable. They are installed in the rear of the
chassis. The system supports operation with a single fan failure (N+1 fan redundancy), but do not run the
system for an extended amount of time without all fan modules installed. Keep removal and replacement time
at three minutes. Remove and replace one fan module at a time.
If you remove a fan or a fan fails, the other fans operate at full speed, which can be noisy.
The fan modules are numbered left to right, for example, FAN1, FAN2, FAN3, FAN4, FAN5, and FAN6.
See Remove and Replace the Fan Module, on page 58 for the procedure for removing and replacing the fan
module.
The following figure shows the location of the fan LED.
Cisco Firepower 4110, 4120, 4140, and 4150 Hardware Installation Guide
23
Overview
Fan Modules

Cisco Firepower 4110 Specifications

General

Power Supply	Dual, hot-swappable
Form Factor	1RU
Firewall Throughput (Multiprotocol)	10 Gbps
Number of 10GE (SFP+) Interfaces	8
Number of 40GE (QSFP+) Interfaces	2
Redundant Power Supply	Yes
Memory	32 GB
Ports	8 x 10GE, 2 x 40GE
Concurrent Sessions	8 Million
Number of 10/100/1000 Interfaces	8
Maximum Connections	8 Million
Management Ports	1 x RJ45
Data Ports	8 x 10GE, 2 x 40GE
Processor	Intel Xeon E5-2600
