topic in the Security Module/Engine Management chapter in the Cisco FXOS Firepower Chassis Manager
Configuration Guide.
Safety Warnings
Take note of the following warnings:
Statement 60UL- and CSA-Certified Equipment Warning
This card is intended to be installed in UL- and CSA-certified equipment in the field by the user in the
manufacturer's defined operator access area. Check the equipment manufacturer to verify/confirm that
your equipment is suitable for user-installed application cards.
Warning
Statement 1029Blank Faceplates and Cover Panels
Blank faceplates and cover panels serve three important functions: they reduce the risk of electric shock
and fire; they contain electromagnetic interference (EMI) that might disrupt other equipment; and they
direct the flow of cooling air through the chassis. Do not operate the system unless all cards, faceplates,
front covers, and rear covers are in place.
Warning
Statement 1030Equipment Installation
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Warning
Statement 1040Product Disposal
Ultimate disposal of this product should be handled according to all national laws and regulations.
Warning
Statement 1073No User-Serviceable Parts
There are no serviceable parts inside. To avoid risk of electric shock, do not open.
Warning
Statement 1077Do Not Operate Unit Without Covers
The covers are an integral part of the safety design of the product. Do not operate the unit without the
covers installed.
Warning
This procedure describes how to install a network module into an empty slot that has never contained a network
module, and how to remove an installed network module and replace it with another network module.
Step 1 To install a new network module for the first time into an empty slot, do the following:
a) Power down the chassis by moving the power switch to the OFF position.
Cisco Firepower 4110, 4120, 4140, and 4150 Hardware Installation Guide
56
Installation, Maintenance, and Upgrade
Install, Remove, and Replace the Network Module
