2-15
Cisco IR800 Integrated Services Router Software Configuration Guide
Chapter 2 Product Overview
Hardware Differences Between IR809, IR829, and the C819HG
The IR829 is a highly ruggedized compact cellular (3G and 4G LTE with GPS and dual SIM) and WLAN
(2.4/5GHz) industrial routers supporting for scalable, reliable, and secure management of fleet vehicles
and mass transit applications.
The 819HG-LTE-MNA-K9: Multimode Cisco LTE 2.0 for carriers that operate LTE 700 MHz (band 17),
1900 MHz (band 2 PCS), 850 MHz (band 5), 700 MHz (band 13), 1900 MHz (band 25 extended PCS)
networks; or 1700/2100 MHz (band 4 AWS) networks; backward-compatible with UMTS and HSPA+:
850 MHz (band 5), 900 MHz (band 8), 1900 MHz (band 2 PCS), and 1700/2100 MHz (band 4 AWS),
with EVDO Rev A/CDMA 1x BC0, BC1, BC10.
Hardware Comparison
Feature IR809 IR829 C819HG
OIR of SIM Yes Yes Yes
Guest OS Support Yes Yes Yes
2G/3G/4G Support Yes, dual SIM support, SKUs available per region
See the Chapter 4, “Cellular Interface”for additional
information.
819(H)G-4G supports dual-SIM
Different SKU’s per region.
SW MC 7750,7700,7710
USB Flash Yes Yes No
USB type A Interface Yes Yes No
Console Port Mini USB Mini USB RJ-45
Alarm Port One Alarm input on IR809 No No
IEEE 802.11a/b/g/n WiFi No Yes, depending on the
platform type.
No
Power Requirements Nominal voltage: 12-48V
DC
Min/max voltage: 9.6 –
60V DC input
Max, Min current: 3A,
0.5A
Nominal voltage: 12V, 24V
DC
Min/max voltage: 9-32V
DC input
Max/Min current: 7.8 A,
2.8 A
Maximum power
consumption: 40 W (no
PoE) and 70W (PoE)
Nominal voltage: 12V, 24V DC
Min/max voltage: 10-36V DC
Maximum power consumption:
26W
Ethernet Ports 2 x RJ45 10/100/1000Mbs 4 x RJ45 10/100/1000Mbs
1 x SFP 1000Mbs
4 x RJ45 10/100 Mbs
1 x GE 10/100/1000Mbs
Serial Ports 2 x RJ45 (1xRS-232 and 1xRS232/RS-485 12 in 1 Smart Serial
Antenna: Main, Diversity
and GPS
Yes Yes 819(H)G-4G has Active GPS
SMA Connector and option for 2
4G antennas
